Convoluted Hose Assemblies



The unique construction of tape wrapped convoluted hose combines the properties of PTFE with lighter weight and greater flexibility than any hose of comparable size.   As with medium pressure smooth bore, tape wrapped convoluted is manufactured with a conductive or non-conductive inner core depending on the demands of the application.   Some applications require a conductive inner liner to dissipate static electrical charges.   High resistivity fluids or gasses at high velocity cause positive electrical charges to build on the inside of the PTFE liner.   If not dissipated to the end of the hose, the charge will build until it arcs through the tube wall to the braid, causing catastrophic hose failure.   To alleviate this, a PTFE inner core is manufactured with a thin conductive liner on the I.D.



Below you will see an example of some hose assemblies we have created for other customers.   It is best to send us a quote for request with type of fittings you would like and how long of an assembly.



 Part  Description  +
Part #: CON-06CB-3875-SS-036
3/8" Tube Stub by 3/8" Tube Stub, 3 feet OAL. Stainless Fittings, Convoluted Conductive PTFE Sta...
Cost: $220.65
Part #: CON-08C1-1231-SS-036
1/2" Male NPT by 1/2" MNPT, 3 feet OAL. 316 SS Fittings with SS Convoluted PTFE SS Braided.
Cost: $141.97
Part #: CON-08C1-1231-SS-048
1/2" Male NPT by 1/2" MNPT, 4 feet OAL. 316 SS Fittings with SS Convoluted PTFE SS Braided.
Cost: $154.35
Part #: CON-12C1-3431-SS-012
3/4" Male NPT by 3/4" MNPT, 1 foot OAL. 316 SS Fittings with SS Convoluted PTFE SS Braided.
Cost: $179.00
Part #: CON-12C1-3431-SS-060
3/4" Male NPT by 3/4" MNPT, 5 feet OAL. 316 SS Fittings with SS Convoluted PTFE SS Braided.
Cost: $179.00
Part #: CON-12C1-3431-SS-076
3/4" Male NPT by 3/4" MNPT, 76 inches OAL. 316 SS Fittings with SS Convoluted PTFE SS Braided.
Cost: $252.75
Part #: CON-16C1-1620-BR-660
-16 Female JIC by -16 Female JIC, 660 inches OAL. Brass Fittings with Convoluted PTFE SS Braided...
Cost: call
Part #: CON-16C1-1620-SS-024
-16 Female JIC by -16 Female JIC, 2 feet OAL. 316 SS Fittings with Convoluted PTFE SS Braided.
Cost: $306.46
Part #: CON-16C1-1631-SS-024
1" Male NPT by 1" MNPT, 2 feet OAL. 316 SS Fittings with Convoluted PTFE SS Braided.
Cost: $259.68
Part #: CON-16C1-1631-SS-048
1" Male NPT by 1" MNPT, 4 feet OAL. 316 SS Fittings with Convoluted PTFE SS Braided.
Cost: $215.98
Part #: CON-16C1-1631-SS-120
1" Male NPT by 1" MNPT, 10 feet OAL. 316 SS Fittings with Convoluted PTFE SS Braided.
Cost: $309.44
Part #: CON-16C1-1631-SS-420
1" Male NPT by 1" MNPT, 35 feet OAL. 316 SS Fittings with Convoluted PTFE SS Braided.
Cost: $716.69
Part #: CON-24C1-2431-CS-480
1-1/2" Male NPT by 1-1/2" MNPT, 40 feet OAL. Carbon Steel Fittings with Convoluted PTFE SS Braided.
Cost: $2,600.10
Part #: CON-24C1-2496-SS-012
1-1/2 SS 150lb. flange by 1-1/2 SS 150lb. flange, 12 inches OAL. 316 SS Fittings with Convoluted...
Cost: $553.68
Part #: CON-24C1-2496-SS-037
1-1/2 SS 150lb. flange by 1-1/2 SS 150lb. flange, 37 inches OAL. 316 SS Fittings with Convoluted...
Cost: $588.30
Part #: CON-24C1-2498-SS-040
1-1/2" Sanitary flange by 1-1/2" Sanitary flange, 37 inches OAL. 316 SS Fittings with Convoluted...
Cost: $461.54
Part #: CON-24C1-964-SS-060
(60 in) -24 Non-conductive, PTFE lined, fiberglass reinforced..inner-core, spiral wire wrapped, ...
Cost: $792.00
Part #: CON-32C1-3220-CS-012
-32 Female JIC by -32 FJIC, 1 foot OAL. Carbon Steel Fittings with Convoluted PTFE SS Braided.
Cost: $555.26
Part #: CON-32C1-3220-SS-012
-32 Female JIC by -32 FJIC, 1 foot OAL. Stainless Steel Fittings with Convoluted PTFE SS Braided.
Cost: $712.88
Part #: CON-32C1-3220-SS-036
-32 Female JIC by -32 FJIC, 3 feet OAL. Stainless Steel Fittings with Convoluted PTFE SS Braided.
Cost: $734.68
Part #: CON-32C1-3231-SS-096
2" Male NPT by 2" Male NPT, 8 feet OAL. Stainless Steel Fittings with Convoluted PTFE SS Braided.
Cost: $881.17
Part #: CON-32C1-9604-SS-108
(108 in) -32 Non-conductive, PTFE lined, fiberglass reinforced..inner-core, spiral wire wrapped,...
Cost: $957.00
